Nestled in Pernik, Bulgaria, the sawdust pellet line plant project of 500kg/h taking beech as raw material is capable of processing wood logs, blocks and sawdust simultaneously. Based upon the client’s requests, our design included stand-alone debarking system which could deal with wood logs separate from the rest of the line. Also, the integrated crusher capable of chipping and then coarsely pulverizing enables raw material to be crushed into qualified one. After the above, material will then be dried, fine crushed, pelleted, cooled and packed in a streamline. The design simplified project structure with fewer use of equipments so that the client’s investment in the line could be effectively saved. Of the line, pellet mill adopts gear-driven system facilitating operators to handle it and ensuring personnel safety. The integrated machine including cooler and vibrating sifter immensely saves floor space. On top of it, adopting mimicked computer system, the electronic scale also works together with the thermo-hemming machine for the benefit of efficiently and swiftly weighing and sealing packages. Below are some site picture in the sawdust pellet line plant.

Pictureof 500kg/h Sawdust Pellet Line Plant Project Site


The whole 500kg/h sawdust pellet line plant project.


Our technician is instructing the worker how to install the ring die pellet machine.


The technician is debugging the sawdust pellet mill on the site.


The workers with our technician take photos in the front of sawdust pellet complete line.

Our translator with worker in the front of sawdust pellet line plant.


Our technician is teaching the worker how to adjust the sawdust moisture.
